Heat Resistant Refractory Fiberglass Mesh Tape for Cable Shielding

Glass fiber adhesive or non-adhesive high heat tape is designed to withstand intense heat and flame. Heat resistant insulation tape can withstand repeated exposures to molten steel, molten aluminum and molten glass, up to 3000°F (1650°C). Mainly in industrial, field and off-shore applications.

Main Features

Outstanding molten splash protection:
Heat resistant tape is a knitted high bulk glass fiber tape, heavily coated with our proprietary compound of iron oxide red silicone rubber. The specially designed compound sheds molten metal splash immediately, so very little heat transfer occurs.

Non-adhesive install, without disconnection:
Heat resistant fiber glass tape has an excellent modulus of elasticity and can wrap any diameter hose or cable - typically in a spiral wrap with a 50% overlap. Can be installed without disconnecting hoses or cables.

High temperature protection mesh tape for hoses and cables
Glass fiber tape withstands continuous exposure to 500°F (260°C), up to 2000°F (1090°C) for 15-20 minutes, and up to 3000°F (1650°C) for 15-30 seconds.

When exposed to flame, the silicone rubber transforms to a crust, creating a protective SiO2 refractory layer.

Available in sizes up to 5" (127 mm) wide.
Continuous operating temp: 500°F (260°C)
Max short term exposure: 3000°F (1650°C)
Molten splash resistance: Outstanding
Flame resistance: Very good
Abrasion resistance: Very good
Flexibility: Outstanding

Silicon Rubber Coated Fiberglass Tape
Anti-flame woven fiberglass tape used as binder tape for fire resistant cables. The cables will exposure to 842 °C for 120 min. with mechanical impact every 5 min.

Refractory Fiberglass PTFE Tape

Similar products: Weld Backing Adhesive Tape
